Recently, I've came across rclone, a powerful "Rsync for cloud storages". It can copy/sync files from and to various cloud provider, such as Amazon S3, Google Drive, Dropbox, One-Drive and so forth. Additionally, if you are using rclone to push your your local backups, you can encrypt them before.

Personally, I am using S3 and Google Drive for different purposes, but had no automatic regular backup into my own infrastructure. So, I decided to install it on my local QNAP NAS. Rcloud as a Go programmed software is precompiled without dependencies for most platforms. That comes in handy, as the QNAP Linux is very minimalistic with few and old software installed.

Install Rcloud

Rcloud is a available as precompiled ARM or x32/64 versions.

First, log into your NAS with ssh:

ssh admin@192.168.178.101

(Same password as the web UI)

Now, try to find out your system architecture:

[~] # uname -a
Linux NAS 3.4.6 #1 Wed Jun 1 13:01:34 CST 2016 armv5tel unknown

The above is a ARM 32bit. If your NAS is a more powerful version, it might be a x64 or similar.

Download the right version from here, e.g.:

mkdir -p /share/backup/sync
cd /share/backup/sync

wget http://downloads.rclone.org/rclone-v1.33-linux-arm.zip
unzip rclone-v1.33-linux-arm.zip
mv rclone-v1.33-linux-arm/rclone .

For the rest of the example, I assume you install rcloud and the following scripts to /share/backup/sync/.

(SHA1 sum for version 1.33 arm: 1dee0f264bd822b77a227855978d0dd8279d9fc5)

SSL

Unfortunately, QNAP has no bundled root certificates, that means no system software (such as Curl or Rclone) can easily access SSL websites. Rclone has a command line switch for disabling SSL validation, but this is neither very nice nor does it work with the Google Drive app authorization flow.

[UPDATE] Generate certificate without installing Perl

One commenter, Elad Eayl, pointed out that you don't need Perl to generate rehashed certificates, as openssl is installed on the NAS.

cd /share/backup/sync
wget --no-check-certificate https://curl.haxx.se/ca/cacert.pem
mkdir certs
cd certs
for filename in cert*pem;do mv $filename `openssl x509 -hash -noout -in $filename`.0; done;
cp *.pem /etc/ssl/certs/

[OLD] 1. Install "Perl" from QNAP App Manager

Web-UI -> App-Store -> Perl. That will install perl binary to /opt/bin,

2. Download & install SSL bundle

Download the cert-bundle from from Curl, unwrap each cert into it's own file, rehash with a perl tool and copy all that over to /etc/ssl/certs (Found here).

cd /share/backup/sync
wget --no-check-certificate https://curl.haxx.se/ca/cacert.pem
mkdir certs
cat cacert.pem | awk 'split_after==1{n++;split_after=0} /-----END CERTIFICATE-----/ {split_after=1} {print > "certs/cert" n ".pem"}'
wget --ca-certificate cacert.pem https://raw.githubusercontent.com/ChatSecure/OpenSSL/master/tools/c_rehash
/opt/bin/perl c_rehash certs
cp certs/* /etc/ssl/certs/

(After a reboot the certs will be reset!)

Example configure Google Drive

Here a copy out from the step-by-step guide of Rclone. Be sure to open the Google Drive authorization url in a webbrowser and paste the validation token that you will receive.

[/share/backup/sync] # ./rclone -v --config rclone.conf config
2016/09/05 16:50:40 rclone: Version "v1.33" starting with parameters ["./rclone" "-v" "--config" "rclone.conf" "config"]
Current remotes:

Name                 Type
====                 ====
s3                   s3

e) Edit existing remote
n) New remote
d) Delete remote
s) Set configuration password
q) Quit config
e/n/d/s/q> n
name> gdrive
Type of storage to configure.
Choose a number from below, or type in your own value
 1 / Amazon Drive
   \ "amazon cloud drive"
 2 / Amazon S3 (also Dreamhost, Ceph, Minio)
   \ "s3"
 3 / Backblaze B2
   \ "b2"
 4 / Dropbox
   \ "dropbox"
 5 / Encrypt/Decrypt a remote
   \ "crypt"
 6 / Google Cloud Storage (this is not Google Drive)
   \ "google cloud storage"
 7 / Google Drive
   \ "drive"
 8 / Hubic
   \ "hubic"
 9 / Local Disk
   \ "local"
10 / Microsoft OneDrive
   \ "onedrive"
11 / Openstack Swift (Rackspace Cloud Files, Memset Memstore, OVH)
   \ "swift"
12 / Yandex Disk
   \ "yandex"
Storage> 7
Google Application Client Id - leave blank normally.
client_id>
Google Application Client Secret - leave blank normally.
client_secret>
Remote config
Use auto config?
 * Say Y if not sure
 * Say N if you are working on a remote or headless machine or Y didn't work
y) Yes
n) No
y/n> n
If your browser doesn't open automatically go to the following link: https://accounts.google.com/o/oauth2/auth?client_id=xxxxxxxxxxxxxxxxxxxxxxx
Log in and authorize rclone for access
Enter verification code> 4/uFcSu-Wyc4ylPxSBo7zLnBCNo0iztzoI6PwP3Lf7riw
2016/09/05 16:51:18 gdrive: Saving new token in config file
--------------------
[gdrive]
client_id =
client_secret =
token = {"access_token":"xxxxxx","token_type":"Bearer","refresh_token":"xxxxxx","expiry":"2016-09-05T17:51:18.744308415+02:00"}
--------------------
y) Yes this is OK
e) Edit this remote
d) Delete this remote
y/e/d> y

You can now list google drive content:

## List the content
$ ./rclone -v --config rclone.conf ls gdrive:
... output snipped

## Download it all
$ ./rclone -v --config rclone.conf sync gdrive: ./google-drive-backup
...

I've also added a S3 bucket without to much problems. Just create an IAM user with bucket read/write access, easiest:

  1. Create S3 Bucket (name needs to be unique over all S3 buckets), remember bucket name + region
  2. Create an IAM User in Security credentials, download credentials
  3. Under tab Permissions: Attach policy: AmazonS3FullAccess
  4. Use credentials from downloaded file when configuring rclone.

Persistent Cronjob with QNAP NAS

As mentioned, QNAP resets most of it directories when rebooting, this includes crontab -e added cronjobs that will be gone after a reboot. Fortunately, there is a workaround as written here:

# run the script every day at 23:01:
$ echo "1 23 * * * /share/backup/sync/backup.sh" >> /etc/config/crontab

Create the backup script into /share/backup/sync/backup.sh (using Vi or by navigating to nfs/samba - might need to fix the permissions in that case).

#!/bin/sh
cd /share/backup/sync/
cp certs/* /etc/ssl/certs/
./rclone --config rclone.conf sync grive: ./google-drive-backup
# ...any more backup stores that you have configured, like:
./rclone --config rclone.conf sync s3:mybucketname ./s3-mybucketname

... and make it executable + reload the crontab into the running system, too.

chmod +x /share/backup/sync/backup.sh
crontab /etc/config/crontab

Happy Backupping!
